matplotlib.pyplot.subplots#

matplotlib.pyplot.subplots(nrows=1, ncols=1, *, sharex=False, sharey=False, squeeze=True, width_ratios=None, height_ratios=None, subplot_kw=None, gridspec_kw=None, **fig_kw)[source]#

Create a figure and a set of subplots.

This utility wrapper makes it convenient to create common layouts of subplots, including the enclosing figure object, in a single call.

Parameters:

nrows, ncolsint, default: 1

Number of rows/columns of the subplot grid.

sharex, shareybool or {'none', 'all', 'row', 'col'}, default: False

Controls sharing of properties among x (sharex) or y (sharey) axes:

• True or 'all': x- or y-axis will be shared among all subplots.

• False or 'none': each subplot x- or y-axis will be independent.

• 'row': each subplot row will share an x- or y-axis.

• 'col': each subplot column will share an x- or y-axis.

When subplots have a shared x-axis along a column, only the x tick labels of the bottom subplot are created. Similarly, when subplots have a shared y-axis along a row, only the y tick labels of the first column subplot are created. To later turn other subplots' ticklabels on, use tick_params.

When subplots have a shared axis that has units, calling Axis.set_units will update each axis with the new units.

Note that it is not possible to unshare axes.

squeezebool, default: True

• If True, extra dimensions are squeezed out from the returned array of Axes:

  • if only one subplot is constructed (nrows=ncols=1), the resulting single Axes object is returned as a scalar.

  • for Nx1 or 1xM subplots, the returned object is a 1D numpy object array of Axes objects.

  • for NxM, subplots with N>1 and M>1 are returned as a 2D array.

• If False, no squeezing at all is done: the returned Axes object is always a 2D array containing Axes instances, even if it ends up being 1x1.

width_ratiosarray-like of length ncols, optional

Defines the relative widths of the columns. Each column gets a relative width of width_ratios[i] / sum(width_ratios). If not given, all columns will have the same width. Equivalent to gridspec_kw={'width_ratios': [...]}.

height_ratiosarray-like of length nrows, optional

Defines the relative heights of the rows. Each row gets a relative height of height_ratios[i] / sum(height_ratios). If not given, all rows will have the same height. Convenience for gridspec_kw={'height_ratios': [...]}.

subplot_kwdict, optional

Dict with keywords passed to the add_subplot call used to create each subplot.

gridspec_kwdict, optional

Dict with keywords passed to the GridSpec constructor used to create the grid the subplots are placed on.

**fig_kw

All additional keyword arguments are passed to the pyplot.figure call.

Returns:

figFigure

axAxes or array of Axes

ax can be either a single Axes object, or an array of Axes objects if more than one subplot was created. The dimensions of the resulting array can be controlled with the squeeze keyword, see above.

Typical idioms for handling the return value are:

# using the variable ax for a single Axes
fig, ax = plt.subplots()

# using the variable axs for multiple Axes
fig, axs = plt.subplots(2, 2)

# using tuple unpacking for multiple Axes
fig, (ax1, ax2) = plt.subplots(1, 2)
fig, ((ax1, ax2), (ax3, ax4)) = plt.subplots(2, 2)

The names ax and pluralized axs are preferred over axes because for the latter it's not clear if it refers to a single Axes instance or a collection of these.

See also

pyplot.figure

pyplot.subplot

pyplot.axes

Figure.subplots

Figure.add_subplot

Examples

# First create some toy data:
x = np.linspace(0, 2*np.pi, 400)
y = np.sin(x**2)

# Create just a figure and only one subplot
fig, ax = plt.subplots()
ax.plot(x, y)
ax.set_title('Simple plot')

# Create two subplots and unpack the output array immediately
f, (ax1, ax2) = plt.subplots(1, 2, sharey=True)
ax1.plot(x, y)
ax1.set_title('Sharing Y axis')
ax2.scatter(x, y)

# Create four polar Axes and access them through the returned array
fig, axs = plt.subplots(2, 2, subplot_kw=dict(projection="polar"))
axs[0, 0].plot(x, y)
axs[1, 1].scatter(x, y)

# Share an X axis with each column of subplots
plt.subplots(2, 2, sharex='col')

# Share a Y axis with each row of subplots
plt.subplots(2, 2, sharey='row')

# Share both X and Y axes with all subplots
plt.subplots(2, 2, sharex='all', sharey='all')

# Note that this is the same as
plt.subplots(2, 2, sharex=True, sharey=True)

# Create figure number 10 with a single subplot
# and clears it if it already exists.
fig, ax = plt.subplots(num=10, clear=True)
