matplotlib.axes.Axes.set#

Axes.set(*, adjustable=<UNSET>, agg_filter=<UNSET>, alpha=<UNSET>, anchor=<UNSET>, animated=<UNSET>, aspect=<UNSET>, autoscale_on=<UNSET>, autoscalex_on=<UNSET>, autoscaley_on=<UNSET>, axes_locator=<UNSET>, axisbelow=<UNSET>, blend_mode=<UNSET>, box_aspect=<UNSET>, clip_box=<UNSET>, clip_on=<UNSET>, clip_path=<UNSET>, facecolor=<UNSET>, forward_navigation_events=<UNSET>, frame_on=<UNSET>, gid=<UNSET>, in_layout=<UNSET>, label=<UNSET>, mouseover=<UNSET>, navigate=<UNSET>, path_effects=<UNSET>, picker=<UNSET>, position=<UNSET>, prop_cycle=<UNSET>, rasterization_zorder=<UNSET>, rasterized=<UNSET>, sketch_params=<UNSET>, snap=<UNSET>, subplotspec=<UNSET>, title=<UNSET>, transform=<UNSET>, url=<UNSET>, visible=<UNSET>, xbound=<UNSET>, xinverted=<UNSET>, xlabel=<UNSET>, xlim=<UNSET>, xmargin=<UNSET>, xscale=<UNSET>, xticklabels=<UNSET>, xticks=<UNSET>, ybound=<UNSET>, yinverted=<UNSET>, ylabel=<UNSET>, ylim=<UNSET>, ymargin=<UNSET>, yscale=<UNSET>, yticklabels=<UNSET>, yticks=<UNSET>, zorder=<UNSET>)[source]#

Set multiple properties at once.

a.set(a=A, b=B, c=C)

is equivalent to

a.set_a(A)
a.set_b(B)
a.set_c(C)

In addition to the full property names, aliases are also supported, e.g. set(lw=2) is equivalent to set(linewidth=2), but it is an error to pass both simultaneously.

The order of the individual setter calls matches the order of parameters in set(). However, most properties do not depend on each other so that order is rarely relevant.

Supported properties are

Property

Description

adjustable

{'box', 'datalim'}

agg_filter

a filter function, which takes a (m, n, 3) float array and a dpi value, and returns a (m, n, 3) array and two offsets from the bottom left corner of the image

alpha

float or None

anchor

(float, float) or {'C', 'SW', 'S', 'SE', 'E', 'NE', ...}

animated

bool

aspect

{'auto', 'equal'} or float

autoscale_on

bool

autoscalex_on

unknown

autoscaley_on

unknown

axes_locator

Callable[[Axes, Renderer], Bbox]

axisbelow

bool or 'line'

blend_mode

blend mode

box_aspect

float or None

clip_box

BboxBase or None

clip_on

bool

clip_path

Patch or (Path, Transform) or None

facecolor or fc

color

figure

Figure or SubFigure

forward_navigation_events

bool or "auto"

frame_on

bool

gid

str

in_layout

bool

label

object

mouseover

bool

navigate

bool

navigate_mode

unknown

path_effects

list of AbstractPathEffect

picker

None or bool or float or callable

position

[left, bottom, width, height] or Bbox

prop_cycle

Cycler

rasterization_zorder

float or None

rasterized

bool

sketch_params

(scale: float, length: float, randomness: float)

snap

bool or None

subplotspec

unknown

title

str

transform

Transform

url

str

visible

bool

xbound

(lower: float, upper: float)

xinverted

unknown

xlabel

str

xlim

(left: float, right: float)

xmargin

float greater than -0.5

xscale

unknown

xticklabels

unknown

xticks

unknown

ybound

(lower: float, upper: float)

yinverted

unknown

ylabel

str

ylim

(bottom: float, top: float)

ymargin

float greater than -0.5

yscale

unknown

yticklabels

unknown

yticks

unknown

zorder

float

Property	Description
`adjustable`	{'box', 'datalim'}
`agg_filter`	a filter function, which takes a (m, n, 3) float array and a dpi value, and returns a (m, n, 3) array and two offsets from the bottom left corner of the image
`alpha`	float or None
`anchor`	(float, float) or {'C', 'SW', 'S', 'SE', 'E', 'NE', ...}
`animated`	bool
`aspect`	{'auto', 'equal'} or float
`autoscale_on`	bool
`autoscalex_on`	unknown
`autoscaley_on`	unknown
`axes_locator`	Callable[[Axes, Renderer], Bbox]
`axisbelow`	bool or 'line'
`blend_mode`	blend mode
`box_aspect`	float or None
`clip_box`	`BboxBase` or None
`clip_on`	bool
`clip_path`	Patch or (Path, Transform) or None
`facecolor` or `fc`	color
`figure`	`Figure` or `SubFigure`
`forward_navigation_events`	bool or "auto"
`frame_on`	bool
`gid`	str
`in_layout`	bool
`label`	object
`mouseover`	bool
`navigate`	bool
`navigate_mode`	unknown
`path_effects`	list of `AbstractPathEffect`
`picker`	None or bool or float or callable
`position`	[left, bottom, width, height] or `Bbox`
`prop_cycle`	`Cycler`
`rasterization_zorder`	float or None
`rasterized`	bool
`sketch_params`	(scale: float, length: float, randomness: float)
`snap`	bool or None
`subplotspec`	unknown
`title`	str
`transform`	`Transform`
`url`	str
`visible`	bool
`xbound`	(lower: float, upper: float)
`xinverted`	unknown
`xlabel`	str
`xlim`	(left: float, right: float)
`xmargin`	float greater than -0.5
`xscale`	unknown
`xticklabels`	unknown
`xticks`	unknown
`ybound`	(lower: float, upper: float)
`yinverted`	unknown
`ylabel`	str
`ylim`	(bottom: float, top: float)
`ymargin`	float greater than -0.5
`yscale`	unknown
`yticklabels`	unknown
`yticks`	unknown
`zorder`	float
