Going native: C++ as a first-class citizen of the Jupyter ecosystem
The team
Project Jupyter
- Consistent set of tools to improve and unify scientific computing workflows,
- An interface between metal and humans, metal and flesh.
From day 1, Jupyter was developed by scientists for scientists and educators
Interactive workflows
Programming languages are not only used to build complex systems, but also to explore and gain insight about
- A computing resource
- A data set
- The outcome of a simulation
Interactive workflows:
- Loading some data
- Running some code
- Showing a visualization
- Running some more code...
The C++ programming language
- Taylored for performances
- With a massive community
- Especially in HPC
(Outside of ROOT) We lack a good story for interative computing in C++
This hurts productivity of C++ software developers.
- C++ is generally considered as a difficult programming language
- Heterogeneous set of tools...
- ... that don't always play well together
- making scientific workflows hard to reproduce
A C++ kernel for Jupyter based on
-
A modern C++ implementation of the Jupyter protocol
-
Cling, the C++ interpreter developed at CERN
Live demo of Xeus-Cling
Jupyter interactive widgets
Another area where Jupyter shines is Jupyter interactive widgets
Jupyter interactive widgets: thick front-end and thin back-end
- A modern C++ back-end for Jupyter interactive widgets
- Uses the front-end implementation of ipywidgets
Live demo of xwidgets
Next goal: implement C++ back-end for other widgets libraries
- bqplot
- ipyleaflet
- pythreejs
- ipyvolume
- ...
- A modern C++ back-end for ipyleaflet
- Uses the front-end implementation of ipyleaflet
Live demo of xleaflet
Voila
The Lazy Tensor Algebra Expression System
Xtensor is a flexible expression system in which any data structure can be plugged, offering the most expressive API to the users.
What is xtensor?
-
A C++ template library for multi-dimensional array manipulation
-
Followings the idioms of the C++ STL
(iterator pairs, clear value semantics)
- But also an API similar to that of numpy
-
What is xtensor?
-
Python bindings to enable xtensor APIs on numpy arrays.
-
Julia bindings to enable xtensor APIs on Julia arrays.
-
R bindings to enable xtensor APIs on R arrays.
-
Cookiecutter projects for authoring of Python, Julia, and R extensions.
What is xtensor?
-
BLAS bindings to enable BLAS operations on xtensor expressions.
-
SIMD acceleration kernels.
- All open-source (BSD License).
Ever heard of numpy ?
Python 3 - numpy
C++ 14 - xtensor
np.array([[3, 4], [5, 6]])
arr.reshape([3, 4])
xt::xarray<double>({{3, 4}, {5, 6}})
xt::xtensor<double, 2>({{3, 4}, {5, 6}})
arr.reshape({3, 4});
np.linspace(1.0, 10.0, 100)
np.logspace(1.0, 10.0, 100)
np.arange(3, 7)
np.eye(4)
np.zeros([3, 4])
np.ones([3, 4])
xt::linspace<double>(1.0, 10.0, 100)
xt::logspace<double>(1.0, 10.0, 100)
xt::arange(3, 7)
xt::eye(4)
xt::zeros<double>({3, 4})
xt::ones<double>({3, 4})
Python 3 - numpy
C++ 14 - xtensor
a[:, np.newaxis]
a[:5, 1:]
a[5:1:-1, :]
np.broadcast(a, [4, 5, 7])
np.vectorize(f)
a[a > 5]
a[[0, 1], [0, 0]]
xt::view(a, xt::all(), xt::newaxis())
xt::view(a, xt::range(_, 5), xt::range(1, _))
xt::view(a, xt::range(5, 1, -1), xt::all())
xt::broadcast(a, {4, 5, 7})
xt::vectorize(f)
xt::filter(a, a > 5)
xt::index_view(a, {{0, 0}, {1, 0}})
np.sum(a, axis=[0, 1])
np.sum(a)
np.prod(a, axis=1)
np.prod(a)
np.mean(a, axis=1)
np.mean(a)
xt::sum(a, {0, 1})
xt::sum(a)
xt::prod(a, {1})
xt::prod(a)
xt::mean(a, {1})
xt::mean(a)
Python 3 - numpy
C++ 14 - xtensor
np.where(a > 5, a, b)
np.where(a > 5)
np.any(a)
np.all(a)
np.logical_and(a, b)
np.logical_or(a, b)
xt::where(a > 5, a, b)
xt::where(a > 5)
xt::any(a)
xt::all(a)
a && b
a || b
np.absolute(a)
np.exp(a)
np.sqrt(a)
np.cos(a)
np.cosh(a)
scipy.special.erf(a)
np.isnan(a)
xt::abs(a)
xt::exp(a)
xt::sqrt(a)
xt::cos(a)
xt::cosh(a)
xt::erf(a)
xt::isnan(a)
Python 3 - numpy
C++ 14 - xtensor
np.random.seed(0)
np.random.randn(10, 10)
np.random.randint(10, 10)
np.random.rand(3, 4)
xt::random::seed(0)
xt::random::randn<double>({10, 10})
xt::random::randint<int>({10, 10}})
xt::random::rand<double>({3, 4}})
np.stack([a, b, c], axis=1)
np.concatenate([a, b, c], axis=1)
xt::stack(xtuple(a, b, c), 1)
xt::concatenate(xtuple(a, b, c), 1)
Broadcasting
xarray<int> a = {{1, 2, 3, 4},
{5, 6, 7, 8},
{9, 10, 11, 12}};
xarray<int> b = { 1, 3, 5, 7};
xarray<int> res = a + b;
Broadcasting
xarray<double> a = {1., 2., 3., 4.};
auto res = xt::broadcast(a, {3, 4});
xarray<double> a, b, c;
// ... initialization of a, b, and c ...
auto res = broadcast(a + b * c, {3, 4});
Iteration
for(auto it=a.begin(); it!=a.end(); ++it)
a.begin({3, 4})
a.end({3, 4})
a.template begin<layout_type::column_major>()
a.template end<layout_type::column_major>()
a.template begin<layout_type::column_major>({3, 4})
a.template end<layout_type::column_major>({3, 4})
How do I try it without installing anything?
http://quantstack.net/xtensor
Live demo
Language bindings with xtensor
A Simple Python extension (1/2)
C++: Using an algorithm from the STL on a numpy array
#include <numeric> // Standard library import for std::accumulate
#include "pybind11/pybind11.h" // Pybind11 import to define Python bindings
#include "xtensor/xmath.hpp" // xtensor import for the C++ universal functions
#define FORCE_IMPORT_ARRAY // numpy C api loading
#include "xtensor-python/pyarray.hpp" // Numpy bindings
double sum_of_sines(xt::pyarray<double>& m)
{
auto sines = xt::sin(m);
// sines does not actually hold any value, which are only computed upon access
return std::accumulate(sines.begin(), sines.end(), 0.0);
}
PYBIND11_PLUGIN(xtensor_python_test)
{
xt::import_numpy();
pybind11::module m("xtensor_python_test", "Test module for xtensor python bindings");
m.def("sum_of_sines", sum_of_sines,
"Computes the sum of the sines of the values of the input array");
return m.ptr();
}
A simple Python extension (1/2)
Python: Using an algorithm from the STL on a numpy array
import numpy as np import xtensor_python_test as xt a = np.arange(15).reshape(3, 5) xt.sum_of_sines(v)
A simple Python extension (2/2)
C++: Create a universal function from a C++ scalar function
#include "pybind11/pybind11.h"
#define FORCE_IMPORT_ARRAY
#include "xtensor-python/pyvectorize.hpp"
#include <numeric>
#include <cmath>
namespace py = pybind11;
double scalar_func(double i, double j)
{
return std::sin(i) - std::cos(j);
}
PYBIND11_PLUGIN(xtensor_python_test)
{
xt::import_numpy();
py::module m("xtensor_python_test", "Test module for xtensor python bindings");
m.def("vectorized_func", xt::pyvectorize(scalar_func), "");
return m.ptr();
}
A simple Python extension (2/2)
Python: Create a numpy-style universal function from a C++ scalar function
import numpy as np import xtensor_python_test as xt x = np.arange(15).reshape(3, 5) y = [1, 2, 3, 4, 5] xt.vectorized_func(x, y)
A Simple Julia extension (1/2)
C++: Using an algorithm from the STL on a Julia array
#include <numeric> // Standard library import for std::accumulate
#include "jlcxx/jlcxx.hpp¨ // CxxWrap import to define Julia bindings
#include "xtensor-julia/jltensor.hpp" // Import the jltensor container definition
#include "xtensor/xmath.hpp" // xtensor import for the C++ universal functions
double sum_of_sines(xt::jltensor<double, 2> m)
{
auto sines = xt::sin(m); // sines does not actually hold values.
return std::accumulate(sines.cbegin(), sines.cend(), 0.0);
}
JULIA_CPP_MODULE_BEGIN(registry)
jlcxx::Module mod = registry.create_module("xtensor_julia_test");
mod.method("sum_of_sines", sum_of_sines);
JULIA_CPP_MODULE_END
A simple Julia extension (1/2)
Julia: Using an algorithm from the STL on a Julia array
using xtensor_julia_test
arr = [[1.0 2.0]
[3.0 4.0]]
sum_of_sines(arr)
A simple Julia extension (2/2)
C++: Create a numpy-style universal function from a C++ scalar function
#include "jlcxx/jlcxx.hpp"
#include "xtensor-julia/jlvectorize.hpp"
double scalar_func(double i, double j)
{
return std::sin(i) - std::cos(j);
}
JULIA_CPP_MODULE_BEGIN(registry)
jlcxx::Module mod = registry.create_module("xtensor_julia_test");
mod.method("vectorized_func", xt::jlvectorize(scalar_func));
JULIA_CPP_MODULE_END
A simple Julia extension (2/2)
Julia: Create a numpy-style universal function from a C++ scalar function
using xtensor_julia_test
x = [[ 0.0 1.0 2.0 3.0 4.0]
[ 5.0 6.0 7.0 8.0 9.0]
[10.0 11.0 12.0 13.0 14.0]]
y = [1.0, 2.0, 3.0, 4.0, 5.0]
xt.vectorized_func(x, y)
A Simple R extension
C++: Using an algorithm from the STL on a R array
// [[Rcpp::export]]
double sum_of_sines(xt::rarray<int> m)
{
auto sines = xt::sin(m); // sines does not actually hold values.
return std::accumulate(sines.cbegin(), sines.cend(), 0.0);
}
A simple R extension
R: Using an algorithm from the STL on a R array
library('xtensor_r_test')
arr <- array(c(c(1, 2), c(3, 4)), dim = c(2, 2)
xtensor_r_test::sum_of_sines(arr)
Generate your packaged xtensor extension
- With a few examples from the documentation
- Unit-tests
- HTML documentation
- Packaging boilerplate (setup.py, build.jl)
Bindings with BLAS libraries
BLAS-based implementation of numpy.linalg
- ISO results with numpy.linalg is main goal
- Seeking adoption by Python to C++ compilers (Pythran, Jet)
- Works with any BLAS implementation (openblas, mkl, netlib)
- See the numpy to xtensor cheat sheet
Continually benchmarking
We benchmark.
A lot!
- C++ dataframe library
- Based on xtensor
- Currently in an alpha stage
Live demo of xframe
Resources:
GitHub
- xeus: github.com/QuantStack/xeus/
- xeus-cling: github.com/QuantStack/xeus-cling/
- xproperty: github.com/QuantStack/xproperty/
- xframe: github.com/QuantStack/xframe/
- xtensor: github.com/QuantStack/xtensor/
- xtensor-blas: github.com/QuantStack/xtensor-blas/
- xtensor-python: github.com/QuantStack/xtensor-python/
- xtensor-r: github.com/QuantStack/xtensor-r/
- xtensor-julia: github.com/QuantStack/xtensor-julia/
- xsimd: github.com/QuantStack/xsimd/
- xtensor-fftw: github.com/egpbos/xtensor-fftw/
- xwidgets: github.com/QuantStack/xwidgets/
- xleaflet: github.com/QuantStack/xleaflet/
- xplot: github.com/QuantStack/xplot/
- xwebrtc: github.com/QuantStack/xwebrtc/
Resources:
Documentation
- xeus.readthedocs.io
- xproperty.readthedocs
- xtensor.readthedocs.io
- xtensor-python.readthedocs.io
- xtensor-julia.readthedocs.io
- xtensor-r.readthedocs.io
- xsimd.readthedocs.io
- xplot.readthedocs.io
- xleaflet.readthedocs.io
